FM Foot

• Spectra Sock made by special Fiber Glass material.
• High wear resistance.
• Suitable for all kind of carbon feet.



Code	Material
S-CF	Fiber Glass

Features

• VACX is a carbon fiber foot which has been developed based on the Winged Foot Structure.
• “Active Vacuum Unit” of the VAC-100 product has been placed on the Winged Foot to generate an elevated vacuum inside of the socket.
• Generated vacuum occurs between user's liner and the socket to prevent pistoning movement and grip the stump firmly
• This system cancels out the need of using locks and silicone liners with the pin system.
• Absorbs high reaction forces of the ground and creates vacuum on each step.
• Totally Multi-axial body, allows 10 degrees of Inversion Eversion
• VACX Foot should be used together with low height Foot Shell, please check through the Foot Shell section at the end of the Carbon feet range.
• Foot Shell should be ordered separately.

Vacuuming the Socket

The socket should be sealed with sleeves to create vacuum-able environment inside. Once the environment is sealed, which is compressed and released during the walking, the vacuum unit draws air from the socket through the one-way valve and evacuates it through the pump. After multiple steps of the user, 15 in. Hg (around 0.5 bar) vacuum is created in the sealed socket

Category Selection

Body Weight	Category
65 - 75 kg	CAT-1
75 - 85 kg	CAT-2
85 - 95 kg	CAT-3
95 - 105 kg	CAT-4

Data Table

Product Name	VACX Foot
Sizes	23 to 28
Advised Activity Level	K3-K4
Max User Weight	105 Kg
Mean Product Lenght	160 mm
Mean Product Weight	740 Gr

Order Example

Features

• Totally carbon fiber body provides high energy return and smooth gait cycle.
• Additional inner carbon plate “Absorbs” surpluss energy and increases life span of the product.
• “3D-Printed Rings Technology” (Patent Pending) provides “Screw-less” connection of carbon plates at toe section. This provides smooth feeling and gait cycle for the user.
• Pyramid of the product is made by Titanium, lightweight and durable against set-screw pressure.
• Suitable for K3-K4 level users.

• Foot Shell is same for all foot types and available in all sizes.
• Foot Shell should be ordered separately by its size and colour.

Category Selection

Body Weight	Category
65-75 kg	CAT-1
75-85 kg	CAT-2
85-95 kg	CAT-3
95-105 kg	CAT-4
105 - 120 kg	CAT-5

Data Table

Product Name	Supreme Foot
Sizes	24 to 28
Advised Activity Level	K3-K4
Max User Weight	120 Kg
Mean Product Lenght	150 mm
Mean Product Weight	480 Gr
Available Foot Shell Color	Beige & Brown

Order Example

Features

• As seen by it's name, this foot mostly focuses on users with Symes amputation.
• Symes foot has stabile M36 Thread and 4-Prong Socket Adapter to be connected with the socket directly.
• Symes foot has the same flexiable carbon structure with the Short Foot, provides high energy return and smooth gait cycle.
• “3D-Printed Rings Technology” has been used, as well as other carbon fiber foots in the product range.

• Foot Shell is same for all foot types and available in all sizes.
• Foot Shell should be ordered separately by its size and colour.

Category Selection

Body Weight	Category
65-75 kg	CAT-1
75-85 kg	CAT-2
85-95 kg	CAT-3
95-105 kg	CAT-4
105 - 120 kg	CAT-5

Data Table

Product Name	Symes Foot
Size	23 to 29
Advised Activity Level	K2-K3
Max User Weight	120 Kg
Mean Product Lenght	50 mm
Mean Product Weight	420 Gr
Available Foot Shell Color	Beige & Brown

Order Example
